Demolition Grapple
The strong fully integrated hydraulic rotator can with stand greater external force.With the design of double balance control valve, the shock on motor would be reduced greatly when the motor is inconversion and when it stops.
The wear-resistant steel is adopted to make the grapple with good wear resistance and long service life.
The design of an integrated motor base reduces the wear of gear and rotary slewing support which effectively protects toothprolongs its life surface and time.
The large volume hydraulic cylinder greatlyimproves the grab capacity.
Specifications
| Specifications | JWB03 | JWB04 | JWB06 | |
| Outline Dimension (mm) | A | (In Developing) | (In Developing) | 1900 |
| B | 1182 | |||
| C | 900 | |||
| D | 1588 | |||
| E | 1340 | |||
| Total Weight (kg) | 430 | 500 | 750 | |
| Capacity (㎡) | 0.23 | 0.3 | 0.5 | |
| Max. Grab Force (kg) | 1600 | 1800 | 2700 | |
| Max.Open Width (mm) | 1500 | 1600 | 1900 | |
| Grab Width (mm) | 700 | 750 | 900 | |
| Total Length (mm) | 1250 | 1336 | 1586 | |
| Suitable Carrier (ton) | 3-3.6 | 7-11 | 12-17 | |
| Working Pressure (kg/cm2) | 160-180 | 160-180 | 180-220 | |
| Working Mode | Motor rotary, 360free rotation | |||
